Mars Multi Band Panel Antenna 698-2700MHz 5dBi


Price:
Sale price$270.00

Description

Up-To-Date Multi Band Panel Antenna covers all the bands for LTE 700 MHz, cellular bands, as well as ISM, WLAN, GSM1800, UMTS and Bluetooth.

ELECTRICAL SPECIFICATIONS

Frequency Range 698-960 / 1710-2700MHz
Impedance 50 Ohm.
Provides a 5dBi gain for 698-960MHz
Provides a 6.5dBi gain for 1710-2700MHz
VSWR <2-1.7
Gain 5/6.5 dBi
Max Input Power 10W
Polarization: Linear & Vertical
3 dB Beam-Width, H-Plane, typ
e. 130/80 3 dB Beam-Width,
E-Plane, type. 70/45

MECHANICAL SPECIFICATIONS

Dimensions 231 x 215 x 37.5 mm
Connector N-Type, Female at bottom (can be installed upside down)
Weight 500g
Mounting Wall Mountable and Az/El Adjustable MNT-22 Mount
Radome UV Protected Polycarbonate
