Acer Dual LNB 10700


Price:
Sale price$55.00

Description

  • Input Frequency Range: 11.7 – 12.75 GHz
  • Output Frequency Range: 1000 – 2050 MHz
  • Local Oscillator Frequency: 10.7 GHz x 2
  • Local Oscillator Stability ±1.0MHz max (@25°C), ±2MHz (@-40°C-+60°C)
  • LO Phase Noise: -50dBc/Hz@1kHz, -80dBc/Hz@10kHz, -100dBc/Hz@100kHz
  • Noise Figure: 0.8dB (@25°C typ)
  • Relector Type: Offset
  • Feedhorn Mounting: 40mm Standard size
  • Conversion Gain; 54-64dB
  • Gain Flatness: ±0.5dB/36MHz, ±3dB max./Full Band
  • Cross Polarity Isolation Typical: 25dB
  • Image Rejection: 45dB min
  • Output P1 dB: 0dBm min
  • Output VSWR in 75Ohms: 2.0:1 max
  • DC Current Consumption: 160mA type
  • Polarity Switching Voltage: Vertical 10.5-14V Horizontal: 16-19V
  • Operating Temperature: -40°C-+60°C
  • Output Connector: 75 Ohm F Type Female
